HyperION
The range of mining HyperION LED cap lamps and charging racks are MineARC’s mid-tier lighting range. The HyperION Cap Lamp range features cap lamps of a high quality, durability and performance.
Compact, lightweight, yet powerful and super-efficient, each cap lamp within the HyperION range is designed to perform better and last longer.
HYPERION LED CORDED CAP LAMPS
Product Overview
Specifications
Feature Image
Spare Parts
Supporting Documents
Product Overview
Detailed with a distinctive green rim, The HyperION Corded Cap Lamp delivers 5880cd; creating a brighter, crisper effect for a more natural light. The end result is a high definition field of vision for underground miners working in difficult conditions.
The HyperION Corded Cap Lamp utilises LED lighting to ensure a long lasting lifespan. HyperION Cap Lamps have an improved battery life compared to other cap lamps, with a discharge time of around 16 hours on the corded model. The battery housing and the lamps are built securely, with every step taken to prevent water and dirt ingress capable of damage.Specifications
- Compact Design
- Long Life Li-Ion Battery
- LED Main Lamp
- Easy Pushbutton Operation
- Low Battery Indication
- Anti-Static Durable Housing
- Low Maintenance
- Water Resistant (IP68)
- Electrical Short Circuit Protection
- Automatic Charger Shut Off
- No Memory Battery
- 2 Auxiliary LED’s
- Working Temp: -20 to 50°C
- Rated Capacity: 6.6Ah
- Rated Voltage: 3.8V
- Rated Current: 0.38A
- Luminous Intensity: 5880cd (high beam); 83cd (low beam)
Feature Image
Spare Parts
| Part Number | Description |
| CLS-HYP-CDD-001 | Bezel Ring |
| CLS-HYP-CDD-002 | Glass and Gasket |
| CLS-HYP-CDD-003 | LED, Reflector and PCB |
| CLS-HYP-CDD-004 | Housing and Ring |
| CLS-HYP-CDD-005 | Steel Clip and Screws |
| CLS-HYP-CDD-006 | 6.6Ah Li-ION Battery Pack |
| CLS-HYP-CDD-007 | Battery Case Complete c/w Cable 1.65m |
| CLS-HYP-CDD-009 | Security Tool |
Supporting Documents
HYPERION LED CORDLESS CAP LAMPS
Product Overview
Specifications
Feature Image
Spare Parts
Supporting Documents
Product Overview
The HyperION Cordless Cap Lamp is a more compact, lighter weight model, designed to match the power and durability of the corded range. The cordless LED lamp utilises an LED globe delivering 5500cd, creating a bright, crisp effect for a more natural light. The end result is a high definition field of vision for underground miners working in difficult working conditions.
The HyperION Cordless Cap Lamp features a compact, low-fuss click-and-go design, and offers over 14 hours of constant use. Unique to the cordless model is a back-lit display screen with battery life indication, providing clear warning when recharge is required.Specifications
- Compact Design
- Long Life Li-Ion Battery
- LED Main Lamp
- Easy Pushbutton Operation
- Low Battery Indication on Back-Lit Display Screen
- Anti-Static Durable Housing
- Low Maintenance
- Water Resistant (IP67)
- Electrical Short Circuit Protection
- Automatic Charger Shut Off
- Working Temp: -20 to 50°C
- Rated Capacity: 4.4Ah
- Rated Voltage: 3.7V
- Rated Current: 350 mA
- Rated Power L.E.D: 0.4W
- Illuminance: 5500cd
- Charging Time: <6 hours
- Charging Voltage: 4.2 V D.C
Feature Image
Spare Parts
| Part Number | Description |
| CLS-HYP-CLS-001 | Front Lamp Housing |
| CLS-HYP-CLS-002 | Light Cup |
| CLS-HYP-CLS-003 | PCB Board |
| CLS-HYP-CLS-004 | Battery Pack |
| CLS-HYP-CLS-005 | Seal Ring |
| CLS-HYP-CLS-006 | Back Case (incl screws) |
| CLS-HYP-CLS-007 | Clip (incl screws) |
| CLS-HYP-CLS-008 | USB Charging Cable |
Supporting Documents
HYPERION LED CAP LAMP CHARGER RACKS
Product Overview
Standard Features
Configurations
Supporting Documents
Product Overview
MineARC Systems’ HyperION Charger Racks have been designed specifically to complement the HyperION Cap Lamp range.
Constructed from robust, hard-wearing powder coated steel, the HyperION Charger Rack’s unique design offers optimal flexibility; allowing you to order a rack specific to your needs. Each row is equipped to house six HyperION Cap Lamps; a five section single-sided rack will charge 30 lamps.
The option of a double-sided rack is available, or alternatively, multiple racks can sit flush side-by-side for a larger charging station. MineARC works directly with its customers to develop the most effective configuration for each site’s specific requirements.Standard Features
- Adaptable design
- Robust, powder coated steel structure
- Plugs directly into mains power
- Single recharging adapter for each lamp
- Free standing unit with adjustable feet
- Designed for 3.7V Li-ion cap lamps
- Input voltage: 110-250VAC 50.60Hz
- Charger voltage: 4.2VDC
- Input power: 50 Watts per module
Configurations
MineARC offers an extensive range of pre-defined single and double-sided configurations, resulting in a tidy charging rack solution for any requirement. Multiple HyperION Racks can sit flush side-by-side, allowing further flexibility when choosing an option to fit your space.
Supporting Documents
TBC TBC TBC
FEATURE IMAGE
Single recharging adapter for each lamp means cap lamps can be added and removed as required.
Robust, versatile design offers optimal flexibility.
Simple turn-and-click locking mechanism makes it easy to add and remove cap lamps from the rack as required.
Convenient battery storage saddle ensures cap lamps stored neatly without being damaged.
